Insert and manage images with perfect Word compatibility.

Supports URLs, base64 data, and maintains positioning for Word export.

<SuperDocEditor
  html={`<p>Images can be inserted inline with text.</p><p><img src="/public/images/extensions/image-landscape.png" alt="Sample landscape" style="width: 300px; height: auto;"></p><p>Images automatically scale and position correctly in both the editor and Word export.</p>`}
  height="350px"
  customButtons={[
[
  {
    label: 'Add from URL',
    onClick: (superdoc) => {
      const editor = superdoc?.activeEditor || superdoc?.editor
      if (!editor?.commands) return
      editor.commands.setImage({
        src: 'https://picsum.photos/id/237/200/150',
        alt: 'External image from URL',
        size: { width: 200 }
      })
    }
  },
  {
    label: 'Add Local Image',
    onClick: (superdoc) => {
      const editor = superdoc?.activeEditor || superdoc?.editor
      if (!editor?.commands) return
      editor.commands.setImage({
        src: '/public/images/extensions/image-chart.png',
        alt: 'Chart visualization',
        size: { width: 250 }
      })
    }
  },
  {
    label: 'Add with Padding',
    onClick: (superdoc) => {
      const editor = superdoc?.activeEditor || superdoc?.editor
      if (!editor?.commands) return
      editor.commands.setImage({
        src: '/public/images/extensions/image-icon.png',
        alt: 'Document icon',
        size: { width: 100 },
        padding: { left: 20, right: 20, top: 10, bottom: 10 }
      })
    }
  }
]
]}
/>

## OOXML Structure

```xml theme={null}
<w:drawing>
  <wp:inline distT="0" distB="0" distL="0" distR="0">
    <wp:extent cx="5715000" cy="3810000"/>
    <wp:docPr id="1" name="Picture 1"/>
    <a:graphic>
      <a:graphicData>
        <pic:pic>
          <pic:blipFill>
            <a:blip r:embed="rId7"/>
          </pic:blipFill>
        </pic:pic>
      </a:graphicData>
    </a:graphic>
  </wp:inline>
</w:drawing>
```

## Use case

* **Document illustrations** - Add diagrams, charts, and screenshots
* **Product documentation** - Include product images and UI screenshots
* **Reports** - Embed data visualizations and infographics
* **Branding** - Insert logos and company graphics
* **Base64 support** - Embed images directly without external files

## Options

Configure the extension behavior:

<ParamField path="allowBase64" type="boolean" default="true">
  Allow base64 encoded images
</ParamField>

<ParamField path="htmlAttributes" type="Object">
  Default HTML attributes for image elements
</ParamField>

## Attributes

Node attributes that can be set and retrieved:

<ParamField path="src" type="string">
  Image source URL or path
</ParamField>

<ParamField path="alt" type="string" default="Uploaded picture">
  Alternative text for accessibility
</ParamField>

<ParamField path="title" type="string">
  Image title/tooltip text
</ParamField>

<ParamField path="size" type="Object">
  Image dimensions
</ParamField>

<ParamField path="size.width" type="number">
  Width in pixels
</ParamField>

<ParamField path="size.height" type="number">
  Height in pixels
</ParamField>

<ParamField path="padding" type="Object">
  Image padding/margins
</ParamField>

<ParamField path="padding.left" type="number">
  Left padding in pixels
</ParamField>

<ParamField path="padding.top" type="number">
  Top padding in pixels
</ParamField>

<ParamField path="padding.bottom" type="number">
  Bottom padding in pixels
</ParamField>

<ParamField path="padding.right" type="number">
  Right padding in pixels
</ParamField>

<ParamField path="marginOffset" type="Object">
  Margin offset for anchored images
</ParamField>

<ParamField path="marginOffset.horizontal" type="number">
  Left/right margin offset
</ParamField>

<ParamField path="marginOffset.top" type="number">
  Top margin offset
</ParamField>

<ParamField path="style" type="string">
  Custom inline CSS styles
</ParamField>

<ParamField path="wrap" type="Object" default="{ type: 'Inline' }">
  Text wrapping configuration. The `type` property controls wrapping mode (e.g., `'Inline'`, `'Square'`, `'Tight'`, `'TopAndBottom'`, `'None'`).
</ParamField>

<ParamField path="transformData" type="Object" default="{}">
  Transform data for rotation, flips, and size extension. Supports `rotation` (degrees), `flipH` (horizontal flip), `flipV` (vertical flip), and `sizeExtension` properties.
</ParamField>

## Commands

### `setImage`

Insert an image at the current position

<Note>
  Supports URLs, relative paths, and base64 data URIs
</Note>

**Example:**

<CodeGroup>
  ```javascript Usage theme={null}
  editor.commands.setImage({ src: 'https://example.com/image.jpg' })
  editor.commands.setImage({
    alt: 'Company logo',
    size: { width: 200 }
  })
  ```

  ```javascript Full Example theme={null}
  import { SuperDoc } from 'superdoc';
  import 'superdoc/style.css';

  const superdoc = new SuperDoc({
    selector: '#editor',
    document: yourFile,
    onReady: (superdoc) => {
      const editor = superdoc.activeEditor;
      editor.commands.setImage({ src: 'https://example.com/image.jpg' })
      editor.commands.setImage({
        alt: 'Company logo',
        size: { width: 200 }
      })
    },
  });
  ```
</CodeGroup>

**Parameters:**

<ParamField path="options" type="ImageInsertOptions" required>
  Image insertion options
</ParamField>

### `setWrapping`

Set the wrapping mode and attributes for the selected image

**Example:**

<CodeGroup>
  ```javascript Usage theme={null}
  // No wrapping, behind document
  editor.commands.setWrapping({ type: 'None', attrs: {behindDoc: true} })

  // Square wrapping on both sides with distances
  editor.commands.setWrapping({
    type: 'Square',
    attrs: {
      wrapText: 'bothSides',
      distTop: 10,
      distBottom: 10,
      distLeft: 10,
      distRight: 10
    }
  })

  // Tight wrapping with polygon
  editor.commands.setWrapping({
    type: 'Tight',
    attrs: {
      polygon: [[0, 0], [100, 0], [100, 100], [0, 100]]
    }
  })

  // Top and bottom wrapping
  editor.commands.setWrapping({
    type: 'TopAndBottom',
    attrs: {
      distTop: 15,
      distBottom: 15
    }
  })
  ```

  ```javascript Full Example theme={null}
  import { SuperDoc } from 'superdoc';
  import 'superdoc/style.css';

  const superdoc = new SuperDoc({
    selector: '#editor',
    document: yourFile,
    onReady: (superdoc) => {
      const editor = superdoc.activeEditor;
      // No wrapping, behind document
      editor.commands.setWrapping({ type: 'None', attrs: {behindDoc: true} })

      // Square wrapping on both sides with distances
      editor.commands.setWrapping({
        type: 'Square',
        attrs: {
          wrapText: 'bothSides',
          distTop: 10,
          distBottom: 10,
          distLeft: 10,
          distRight: 10
        }
      })

      // Tight wrapping with polygon
      editor.commands.setWrapping({
        type: 'Tight',
        attrs: {
          polygon: [[0, 0], [100, 0], [100, 100], [0, 100]]
        }
      })

      // Top and bottom wrapping
      editor.commands.setWrapping({
        type: 'TopAndBottom',
        attrs: {
          distTop: 15,
          distBottom: 15
        }
      })
    },
  });
  ```
</CodeGroup>

**Parameters:**

<ParamField path="options" type="Object" required>
  Wrapping options
</ParamField>

## Types

### `ImageInsertOptions`

Options for inserting an image

<Expandable title="Properties">
  <ResponseField name="src" type="string" required>
    Image source URL or data URI
  </ResponseField>

  <ResponseField name="alt" type="string">
    Alternative text
  </ResponseField>

  <ResponseField name="title" type="string">
    Image title
  </ResponseField>

  <ResponseField name="size" type="Object">
    Image dimensions
  </ResponseField>

  <ResponseField name="size.width" type="number">
    Width in pixels
  </ResponseField>

  <ResponseField name="size.height" type="number">
    Height in pixels
  </ResponseField>
</Expandable>

## Source code

<SourceCodeLink path="packages/super-editor/src/editors/v1/extensions/image/image.js" />
